| MOQ: | 2㎡ |
| 価格: | USD115/㎡ |
| 標準パッケージ: | EPE Foam wrapped |
| 配達期間: | 25-30days |
| 決済方法: | L/C,T/T,Western Union,PayPal |
| 供給能力: | 10000㎡ |
Designed for discerning architects and homeowners, our Premium Thermal-Break Aluminum Fixed Window combines minimalist aesthetics with cutting-edge thermal and structural performance. Ideal for modern residential, commercial, and public buildings, this fixed window provides uninterrupted views, exceptional insulation, and a sleek aluminum profile that enhances any façade.
Thermal-Break Technology
Equipped with high-quality polyamide thermal break strips, the window significantly reduces heat transfer, improving indoor comfort and energy efficiency throughout the year.
High Structural Integrity
Manufactured from T5-grade aluminum alloy with a wall thickness of 1.6mm–2.0mm, this fixed window offers excellent resistance to wind load, impact, and corrosion, making it suitable for high-rise or coastal applications.
Air & Water Tightness
Multi-layer EPDM sealing strips and precision corner joining ensure outstanding air and water tightness, complying with international standards for weather resistance.
Glazing Options
Compatible with double or triple glazed units, the window can incorporate low-E, laminated, or tinted glass for enhanced insulation, UV protection, and acoustic control.
Frameless Interior View
The fixed glass sits flush inside the aluminum frame, giving the interior a frameless look. Exterior views remain wide and uninterrupted.
Custom Finish Options
Available in powder-coated, anodized, and wood-grain finishes. Color matching is possible via RAL or custom palettes for a tailored design.
Luxury residential villas and condominiums
Commercial office buildings and lobbies
Hospitality projects (hotels, resorts, etc.)
Gallery or showroom façade walls
Stairwells, corridors, or light wells in modern architecture
| Specification | Details |
|---|---|
| Frame Material | High-grade Aluminum Alloy (6063-T5) |
| Frame Depth | 60mm / 75mm / Custom |
| Glass Options | Double/Triple Glazing, Low-E, Laminated |
| Thermal Break | Yes (Polyamide Strip 14.8mm or 24mm) |
| Air Tightness | Class 4 (EN12207) |
| Water Tightness | Class 8A (EN12208) |
| Wind Load Resistance | Class C5 (EN12210) |
| Acoustic Insulation | Up to 42dB (with triple glazing) |
| Finish Options | Powder Coated, Anodized, Wood Grain |
Unlike ordinary fixed windows, this model is engineered for superior thermal insulation, noise reduction, and long-term stability. Its clean lines and robust structure make it suitable for minimalist or high-end modern design projects where performance cannot be compromised.
We support OEM/ODM orders and provide full customization in dimensions, frame finish, glass type, and accessories. Lead times are 15–30 days depending on order volume. Global shipping and export support available.
Clear and trackable logistics process
ELOYD understand the importance of timely andsafe delivery. That's why we offer an efficient logisticsservice, letting you track your order anytime.
Comprehensive door-to-door transportationservice
We offer a complete door-to-door transportation servicefrom our factory to your doorstep, aiming to provide youwith a pleasant shopping experience.
1.Product Packaging 2.Product Sorting 3.Dispatch 4.Confirmation of Goods 5.Logistics Unloading 6.Buyer Receiving
